Roland V-8HD HDMI Video Switcher

Roland V-8HD HDMI Video Switcher

Maximum Connectivity

The V-8HD seamlessly mixes eight HDMI sources with Full HD support, even when the sources have mismatched frame rates and color spaces. And with the built-in scalers on two of the HDMI inputs, you can easily interface with client-provided sources like computers, tablets, smartphones, gaming consoles, and legacy 4:3 devices.

More HDMI Inputs and Outputs

With the V-8HD's eight HDMI inputs and three outputs, you're able to offer clients a vast amount of creative freedom, without increasing the budget.

Set Up Layers, Effects, and Keys

With the V-8HD's five composition layers, you'll always keep audiences engaged with visually appealing content.

Seamless Memory Recall

With the V-8HD, storing and recalling unique looks requires only a few button presses. The eight memory presets and powerful composition effects engine work together to provide a completely seamless load between the different looks.

Separate Feeds for Separate Needs

The V-8HD has assignment buttons for sending any of your connected input devices to a dedicated aux output without affecting the main feed. It's also possible to synchronize the aux output with the program output, giving you a built-in 2x distribution amp.

Built-In Multiviewer Display

The V-8HD's bright, 4.3" multiviewer display means less gear to buy and haul to the gig. From a single screen, you can monitor all eight video inputs, PGM, and PVW plus menu overlay. Input windows show camcorder recording status and embedded audio levels. Connect a larger external TV for an immense multiviewer experience, or to make menu changes without moving the focus from the action.

Audio and Effects

The studio-grade, 18-channel audio mixer blends signals from the eight HDMI inputs and stereo RCA inputs, while a feature-packed preset effects library provides setups for everyday production environments like meetings and interviews, plus challenging situations that require wind noise reduction and microphone de-essing.

Automated Video Switching

Input Scan switches input sources randomly or in sequence, while Preset Memory Scan switches between preset memories. Beats per Minute (BPM) Sync is also available, automatically switching Preview and Program at a specified tempo.

Record Triggering and Confirmation

Via HDMI, the V-8HD operator can trigger Atomos recorders to start and stop recording. And some camcorders even display a recording confirmation icon on the input channel of the V-8HD's multiviewer screen, letting you keep an eye on the recording status while staying focused on other critical tasks.

V-8HD iPad Remote Control Utility

The dedicated V-8HD remote control app turns an iPad into an efficient touch interface for the V-8HD. Run essential switching functions, mix audio with virtual faders, change settings and effect parameters quickly, and create up to eight custom scenes for fast, efficient setup changes.

Mix Effects
Available M/E Layers5 M/E
Effect Types8 x Graphic, Transition, Chroma Key, Alpha Key, Luma Key
Downstream Keys2 x Chroma, Luma
Generators1 x Pattern
Audio Mixing18-Channel Mixing
Processing
Switching TypePushbutton
Processing Resolution1080p at 29.97/50/59.94
Color Processing8-Bit 4:2:2 YCbCr
Audio Processing48 kHz / 24-Bit
Input
Number of Video Input Sources8
Video Input Connectors8 x HDMI Female
Input Video FormatHDMI (8-Bit 4:2:2 YCC)
1080p: 23.98/24/29.97/30/50/59.94/60 fps
1080i: 50/59.94 fps
720p: 50/59.94 fps
576p: 50 fps
PAL: 50 fps
480p: 59.94 fps
NTSC: 59.94 fps
WUXGA (1920 x 1200): 60 fps
Audio Input Connectors1 x 2RCA Stereo Analog Female
Input Audio FormatAnalog: 48 kHz / 24-Bit
Embedded Audio InputHDMI: 2-Channel (per Input)
Output
Video Output Channels3
Video Output Connectors2 x HDMI Female (Loop Output)
1 x HDMI Female (Preview)
Output Video FormatHDMI (8-Bit 4:2:2 YCC)
1080p: 50/59.94 fps
1080i: 50/59.94 fps
Audio Output Connectors1 x 1/4" TRS Stereo Analog Female
Output Audio FormatAnalog: 48 kHz / 24-Bit
Embedded Audio OutputHDMI: 2-Channel (per Output)
Multiview Output1-Way Multiview viaHDMI
Monitor Output1 x HDMI
Connectivity
Other I/O1 x USB Type-A Firmware Input
1 x USB Type-B Control Input
HDCP SupportYes
Display
Display Size4.3"
Screen Resolution480 x 272
Power
Power Connector1 x Barrel (12 to 17 VDC) Input
Power ConsumptionDevice: 3.3 A39.6 W
Packaging Info
Package Weight7.67 lb
Box Dimensions (LxWxH)16 x 11.5 x 7.3"
