Blackmagic Design Studio Camera 4K 2

Blackmagic Design Studio Camera 4K 2

·         Micro Four Thirds Lens Mount

·         Resolutions up to UHD 3840x2160

·         10" LCD (1920 x 1200 Resolution)

·         Built-In Talkback

·         Built-In 4 Hour Battery

·         Illuminated Tally

·         12G-SDI & Optical Fiber Video I/O

·         XLR Audio Connections

·         4-Pin XLR Power Connector

·         Magnesium Alloy Body

The Blackmagic Studio Camera 4K is a compact and lightweight broadcast camera designed for live production. Constructed from a magnesium alloy body, the camera is light even for travel, yet durable enough for use in the field. It has a large 10" LCD screen with detachable sunshade and an active Micro Four Thirds lens mount for compatibility with a wide range of lenses. The camera also provides features you'd expect to find in larger studio cameras, such as tally indicators, talkback, XLR audio connections, and 12G-SDI and optical fiber video inputs/outputs.

The camera offers Ultra HD resolutions at frame rates of 23.98, 24, 25, 29.97, and 30p. It also offers 1080i and 1080p resolutions at frame rates of 23.98, 24, 25, 29.97, 30, 50, 59.94, and 60. It outputs 10-bit 4:2:2 video via its 12G-SDI or optical fiber outputs. For power, the camera has a built-in battery that lasts up to 4 hours on a single charge. The camera can also provides a standard 4-pin XLR power input for external power sources. The internal battery provides the added benefit of being able to hot swap external batteries without having to power off or interrupt recording.

The camera control buttons have been placed right below the viewfinder, letting you easily make adjustments without taking your eyes off your subject. The camera can also be controlled via ATEM switchers with a future update. The update will be available as a free download for both the camera and the ATEM switchers, and will send camera control commands down the SDI program feed to the camera to control focus, iris, gain, and more straight from any ATEM production switcher.

Camera
Sensor Size13.056 x 7.344 mm
Lens MountMicro Four Thirds (active), with auto iris control button
Shutter Speed1/50 to 1/2000 second
White BalanceSix presets: 3200K, 4500K, 500K, 5600K, 6500K, and 7500K
Resolution3840 x 2160p 23.98/24/25/29.97/30
1920 x 1080p 23.98/24/25/29.97/30/50/59.94/60
1920 x 1080i 50/59.9/60
Display
TypeIntegrated TFT-LCD
Size10.1" (25.7 cm)
Resolution1920 x 1200
Connections
ComplianceSMPTE 292M
SDI Video Output1 x 12G-SDI, 10-bit 4:2:2
SDI Video Input1 x 12G-SDI
Reference Input1 x Reference input
Optical Fiber Compatibility6G Optical Fiber input and output
Analog Audio Input2 x XLR analog, switchable between mic and line levels; Phantom power support
Analog Audio OutputAviation headphone (Fixed Wing Plugs) output for talkback and audio monitoring
SDI Audio Output2 channels in 12G-SDI 48 Khz and 24-bit
2 channels for talkback on channel 15-16
Remote Control1 x 2.5 mm LANC for iris and focus control
SDI CCU control from ATEM
USB1 x USB 2.0 Mini-B port for software updates
General
MicrophoneIntegrated stereo microphone
Mounting Options2 x 3/8" tripod mount
10 x 1/4"-20 threaded holes (4 on top of the camera, 3 on left, 3 on right)
ControlsPush button controls for navigating menus
Operating Systems SupportedMac OS X 10.8 Mountain Lion or later
Windows 7 or later
Power Requirements11 to 30 VDC
External Power Input1 x 4-pin XLR
BatteryIntegrated lithium ion polymer battery
Battery LifeApprox. 4 hours
Battery Charge TimeApprox. 4 hours
Operating Temperature32 to 104°F (0 to 40°C)
Storage Temperature-4 to 113°F (-20 to 45°C)
Relative Humidity0 to 90%, non-condensing
Dimensions (W x H x D)10.05 x 7.66 x 4.47" (25.53 x 19.46 x 11.35 cm)
Weight4.44 lb (2.01 kg)

Technical
Display Size 10"
Battery LP-E6
Warranty 1 Year Service & Spareparts
