Sony PXW-Z280 Professional 4K 3-CMOS XDCAM Camcorder

Product Highlights

• Three 1/2" Exmor R CMOS Sensors
• 4K 60p Recording
• Integrated 17x Optical Zoom Lens
• Electronic Variable ND Filter
• Supports XAVC Intra/Long, MPEG HD, DVCAM
• Supports S-Log 3
• Supports HLG for an HDR Workflow
• Simultaneous 4K/HD Recording
• 12G-SDI Output Supports 4K 60p
• Built-In 2.4/5 GHz Wi-Fi
•


• Sony's PXW-Z280 4K 3-CMOS 1/2" Sensor XDCAM Camcordercontinues the fine tradition of the XDCAM series of cameras. It captures 4K at up to 60p relying on three 1/2" Exmor R sensors that provide improved low-light capability when compared to standard sensors. The camera integrates a 17x optical zoom lens and an electronic variable ND filter. The camera supports modern codecs such as XAVC, as well as legacy codecs such as MPEG HD and DVCAM, allowing you to use one camera to shoot 4K, HD, or SD video.

  The camera supports S-Log 3 for improved performance, and HLG (Hybrid Log Gamma) which allows you to shoot and deliver footage compatible with both HDR (high dynamic range) and SDR (standard dynamic range) without needing laborious post-production work. You can record in both 4K and HD simultaneously, or output 4K 60p via the built-in 12G-SDI output. The camera features built-in 2.4 and 5 GHz Wi-Fi.




  Specifications :

  Imaging
  Image Sensor	3-Chip 1/2" CMOS Sensor
  Effective Sensor Resolution	3840 x 2160
  Signal-to-Noise Ratio	63 dB
  Minimum Illumination	0.0013 lux

  Lens
  Focal Length	5.6 to 95.2mm
  35mm Equivalent Focal Length	30.3 to 515mm
  Optical Zoom Ratio	17x
  Maximum Aperture	f/1.9
  Minimum Aperture	f/16
  Minimum Focusing Distance	Wide: 2.0" / 5.1 cm Telephoto: 31.5" / 80.0 cm
  Filter Size	77 mm
  Control Rings	Focus Ring Zoom Ring Iris Ring
  Image Stabilization	Optical Image Stabilization
  Focus Control	Autofocus Manual Focus

  Camera
  Shutter Speed	1/24 to 1/8000 sec
  Built-In ND Filter	Mechanical Filter Wheel with Clear, 2 Stop (1/4), 4 Stop (1/16), 6 Stop (1/64) ND Filters and a 2 to 7 Stop Electronic ND Filter
  Built-In Microphone Type	Stereo
  Recording Media	2 x SxS Card Slots

  Recording
  Broadcast System Compatibility	NTSC, PAL
  Variable Frame Rates	1 to 60 fps
  Audio Recording	XAVC: 4-Channel 24-Bit 48 kHz LPCM Audio

  Interfaces
  Video Connectors	1 x BNC (Component) Output 1 x BNC (12G-SDI) Output 1 x HDMI Output
  Audio Connectors	2 x 3-Pin XLR Mic Level Input 1 x 1/8" (3.5 mm) Stereo Headphone Output
  Other I/O	1 x BNC Timecode Input 1 x BNC Timecode Output 1 x BNC Genlock Input 1 x 2.5 mm LANC Control  1 x USB Micro-B Data  1 x USB Type-A  1 x USB Type-C  1 x RJ45 LAN Data
  Wireless Interfaces	2.4 GHz, 5 GHz Wi-Fi, NFC
  Global Positioning	GPS

  Display
  Display Type	LCD
  Screen Size	3.5"
  Screen Resolution	1,560,000 Dots
